Model

RCA4

Capacity

4 Kg

6 Kg

Confirming IS No.

15683

15683

Fire Rating

1A, 13B

2A, 21B

Operating Temperature

,-20°c to + 55°c

,-20°c to + 55°c

Min. Jet Length ( in Mtrs.)

2 Mtrs.

2 Mtrs.

Discharge Percentage Min

95%

95%

Discharge Time Min.

13 Sec.

13 Sec.

Charge Pressure

15Kgf/cm2

15Kgf/cm2

Test Pressure

35Kgf/cm2

35Kgf/cm2

Operating Valves

Squeeze Grip Type

Squeeze Grip Type

Extinguisher Media

HFC 236fa

HFC 236fa

Expellant

Dry Nitrogen

Dry Nitrogen

Anti Corrosive Treatment

Phosphating (7 Tanks)

Phosphating (7 Tanks)

Painting

Epoxy Polyester Pow. Coat.

Epoxy Polyester Pow. Coat.

Tare Weight

2.3 KGS

3 KGS

Gross Weight

6.3 KGS

9 KGS
